Pro2 4-Zone Audio Power Amplifier Integrated 4 Source Stereo 285mm Black
PRO1323 PRO2 4-ZONE AUDIO POWER AMPLIFIER
With a diverse range of inputs, including digital (optical or coaxial) and dynamic microphone inputs, and the ability to adjust each zone's volume independently, the PRO1323 is a quick and easy way of adding audio in up to four rooms. It also features a Loop-out for expanding to another unit, increasing the number of zones further.
- Four-in and five-out
- IN: 1 × Digital (Optical / Coaxial selectable), 1 × RCA Stereo, 1 × 3.5mm Stereo, 1 × Dynamic Microphone input
- OUT: 4 × Speaker output + 1 × Headphone output
- Built-In audio digital to analogue converter (DAC)
- Independent microphone level control
- Individual speaker volume control
- Provides line loop-out for expanding to more zones
- Large detachable terminal block (supplied) for quick and easy installation
- Screw terminals handle wire sizes from 24 to 12 gauge
Specifications
Specifications
Speaker Audio Power Amplifier (×4)
| Amplifier Type | Stereo Class-D |
| Output Power | 15W (RMS) per channel (@ RL = 4Ω (Ohm)) |
| THD+N | 0.06% (@ RL = 8Ω (Ohm), f = 1 kHz) |
| Minimum Load Resistance | 4Ω (Ohm) |
| Other | Includes Speaker Protection Circuit |
Earphone Audio Power Amplifier
| Output Power | 105mW (RMS) per channel |
| THD+N | 0.05% (@ RL = 16Ω (Ohm), f = 1 kHz) |
| Minimum Load Resistance | 16Ω (Ohm) |
Power & Dimensions
| Power Consumed | 9A Max |
| Power Source | 12V DC (Included) |
| Size (L×W×H) | 285mm × 128mm × 43mm |
| Net Weight (Unit Only) | 0.8kg |
Includes:
1 x Amplifier
